| สถานที่กำเนิด: | จีน |
|---|---|
| ชื่อแบรนด์: | FANRYN |
| ได้รับการรับรอง: | CE, ASTM E84, EN 13501 12018 |
| หมายเลขรุ่น: | ผ้าห่มแก้ว |
| จำนวนสั่งซื้อขั้นต่ำ: | 1 * 40HQ ต่อข้อกำหนด |
| ราคา: | 0.2-5$/m2 |
| รายละเอียดการบรรจุ: | ถุงพลาสติกสูญญากาศ+ถุงผ้า |
| เวลาการส่งมอบ: | 7-10 วัน |
| เงื่อนไขการชำระเงิน: | ที/ที |
| สามารถในการผลิต: | 1*40HQ 7 วัน |
| การนำความร้อน: | 0.031-0.042 วัตต์/เมตร·เค | ความหนาแน่น: | 10-100 กก./ลบ.ม |
|---|---|---|---|
| ผลกระทบต่อสิ่งแวดล้อม: | รีไซเคิลได้เป็นมิตรกับสิ่งแวดล้อม | ทนไฟ: | ไม่ติดไฟ,คลาส A1 |
| ค่าสัมประสิทธิ์การดูดซับเสียง: | 1.03 วิธีการสะท้อนกลับของผลิตภัณฑ์ 24 กก./m3 2000Hz | ดูดซึมน้ำ: | <1% |
| ชื่อผลิตภัณฑ์: | ฉนวนใยแก้วกันความร้อน | แอปพลิเคชัน: | ฉนวนกันความร้อนสำหรับอาคาร อุปกรณ์อุตสาหกรรม |
| ความหนา: | 25-200 มม. | วัสดุ: | ผ้าขนสัตว์ |
| สี: | สีเหลือง, สีน้ำตาล, สีแดง | อุณหภูมิ ความทนทาน: | -270°C ถึง 350°C |
| ขนาด: | แตกต่างกันไป (เช่น บอร์ดขนาด 600x1200 มม.) | ||
| เน้น: | brown glass wool insulation blanket,sound absorption fiberglass insulation roll,PVC faced glass wool blanket |
||
Products Description
Glass wool is an inherently non-combustible material that provides exceptional thermal and acoustic insulation. In a fire scenario, it ensures superior safety by emitting zero toxic fumes, positioning it as a fundamentally responsible choice for any building application.
Premium brown glass wool builds upon this foundation by being specifically engineered as formaldehyde-free. Combining inherent fire safety with guaranteed indoor air quality, it delivers a comprehensive solution for projects demanding uncompromising technical performance and a verifiably healthy indoor environment.
Product feature of the red glass wool blanket
1. Rapid Thickness Recovery: Returns to its nominal thickness within 24 hours of unpacking, ensuring design-specified insulation performance from day one.
2. Uniform Consistency: Guarantees homogenous thickness and color throughout the product, delivering predictable and reliable results across all applications.
3. Exceptional Dimensional Stability: Maintains its shape and structure over time, preventing sagging or compression for lasting thermal efficiency.
4. Low-Dust Installation: Manufactured from soft, continuous fibers that minimize airborne dust and fly, creating a cleaner and healthier work environment.
5. Formaldehyde-Free: Certified to meet the strictest indoor air quality standards (e.g., NAF), contributing to healthier building interiors from the core structure out.
Product Specifications
|
Item |
Unit |
Index |
Standard |
|
Density |
kg/m3 |
10-100 |
GB/T 5480.3-1985 |
|
Average fiber dia. |
µm |
5.5 |
GB/T 5480.4-1985 |
|
Water content |
% |
≤1 |
GB/T 3007-1982 |
|
Grade of combustibility |
|
Non-combustible Grade A |
GB 8624-1997 |
|
Reshrinking temp |
℃ |
≥250 |
GB/T 11835-1998 |
|
Thermal conductibility |
w/m.k |
0.038-0.06 |
GB/T 10294-1988 |
|
Hydrophobicity |
% |
≥98.2 |
GB/T 10299-1988 |
|
Moisture rate |
% |
≤5 |
GB/T 16401-1986 |
|
Sound absorption coefficient |
|
1.03 product reverberation method 24kg/m32000HZ |
GBJ 47-83 |
|
Slag inclusion content |
% |
≤0.3 |
|
Product size of the glass wool blanket
|
Density(kg/m3) |
Thickness(m) |
Length (m) |
Width (m) |
Rolls/packing |
|
|
10-48 |
0.025-0.2 |
5-30 |
0.6 |
2 rolls |
|
|
10-48 |
0.025-0.2 |
5-30 |
1.1 |
1 roll |
2 rolls overlapping |
|
10-48 |
0.025-0.2 |
5-30 |
1.15 |
1 roll |
2 rolls overlapping |
|
10-48 |
0.025-0.2 |
5-30 |
1.2 |
1 roll |
2 rolls overlapping |
|
10-48 |
0.025-0.2 |
5-30 |
1.25 |
1 roll |
2 rolls overlapping |
Product application of the glass wool blanket
Engineered Solutions For:
• Thermal Insulation for Building Walls
• Weather & Energy Protection for Steel Buildings
• Sound Dampening in Interior Partitions
• Lightweight Thermal & Acoustic Lining in Transportation
• Noise Control & Acoustic Comfort
Production Facing For glass wool blanket
Foil-Scrim-Kraft Facing
Alum Glass Cloth Facing
Fiberglass Tissue
Production packing of the glass wool blanket
1. Vacuum plastic bag +woven bag
2. Vacuum plastic bag +woven bag +PE bag
3. Vacuum plastic bag+ PE shrinking bag
4. PE shrinking bag
Note: OEM is acceptable
FAQ:
Q1: How to guarantee the quality of the products?
A1: Our experienced QC team will inspect product's quality in every process
Q2: How to pack exported goods?
A2: Our standard package is Vacuum plastic bag +woven bag (Standard Export Packing).
Q3: What is your lead time for one 40HC container order?
A3: Usual 10-15 work days after placing order.
Q4: What is your advantage on glass wool blanket?
A4: Our glass wool blanket can be freely cut in construction according the shape required.
Q5: About the after-sale service, how to solve the problems occurred of your overseas customer in time?
A5: The warranty of our products is one year. If our products or packing exist quality problem, we will replace or compensate accordingly.
