| Place of Origin: | CHINA |
|---|---|
| ชื่อแบรนด์: | FANRYN |
| Minimum Order Quantity: | one 40HQ |
| Packaging Details: | Plastic bag |
| Delivery Time: | 15 work days |
| Payment Terms: | T/T |
| Lifespan: | 20-50 years | Waterabsorption: | <1% |
|---|---|---|---|
| Environmentalimpact: | Recyclable and eco-friendly | Density: | 40-200 kg/m³ |
| Fireresistance: | Non-combustible, Class A1 | Temperatureresistance: | -40°C to 700°C |
| Moistureresistance: | High | Compressionstrength: | ≥10 kPa |
| Soundabsorptioncoefficient: | 0.85 | Material: | Mineral Wool |
| Applications: | Building insulation, HVAC systems, industrial equipment | Dimensions: | Standard sizes available, customizable |
| Installationmethod: | Mechanical fixing or adhesive bonding | Productname: | Thermal Insulation Mineral Wool |
| Thermalconductivity: | 0.035 W/m·K |
FANRYN Fiberglass Ceiling Boards are designed for environmentally conscious projects. Made from recyclable fiberglass wool, these tiles support sustainable building practices while delivering high performance in thermal insulation and noise reduction. Suitable for LEED and green building certifications.
| Material | Fiberglass wool board |
| Density | 90-130kg/m3 |
| Face | Painting laminated with decorative fiberglass tissue or PVC facing |
| Color | White, black and others to order |
| Fire-resistant | Class A |
| Thermal-resistant | ≥0.5 (m2·k/w) |
| NRC | 0.9-1.0 |
| Humidity | Dimensionally stable with RH up to 95% at 40℃,no sagging, wrapping or delaminating |
| Moisture rate | ≤1%(JC/T670-2005) |
| Environmental impact | Tiles and packing are fully recyclable |
| safety | Limit of radionuclides in building materials specific activity of 226Ra: Ira≤1.0 specific activity of 226Ra, 232Th, 40K: Ir≤1.3 |
| SIZE | CARTON/40HQ | PIECES/CARTON | M2/40HQ |
|---|---|---|---|
| 600*600*15MM | 532 | 20 | 3830.4 |
| 600*1200*15MM | 266 | 20 | 3830.4 |
| 600*600*20MM | 532 | 15 | 2872.8 |
| 600*1200*20MM | 266 | 15 | 2872.8 |
| 600*600*25MM | 532 | 12 | 2298.24 |
| 600*1200*25MM | 266 | 12 | 2298.24 |
Fully Recyclable: Tiles and packaging are 100% recyclable.
Low Environmental Impact: Meets strict radionuclide safety limits.
Energy Efficient: Thermal resistance ≥0.5 m²·K/W.
Durable & Stable: Resistant to humidity and moisture.
Aesthetic Flexibility: Available in multiple finishes and colors.
Green offices
Educational institutions
Healthcare facilities
Retail environments
Public halls & libraries
Works with 15mm or 24mm exposed grids
Easy to cut and install
Compatible with inch or metric grid systems
600x600mm and 600x1200mm panels
Thickness options: 15mm, 20mm, 25mm
Optimized loading for container shipping
